Video Input and Transmission
Connectable to Turbo HD/HDCVI/AHD/CVBS signal input Up to 2-ch 1080p IP cameras input Long distance transmission over UTP and coaxial cable: max. 1200m for 720p Turbo HD signal
Compression and Recording
One-key enable H.264+ compression to improve encoding efficiency by up to 50% and reduce data storage costs Supports 1080p lite of all channels and when enabled, the image effect is similar with 1080p
Video/Audio InputAudio Input: 1-ch
Video Compression: H.264,H.264+
Analog Video Input: 8-ch
Analog and HD-TVI video input: 1080p25, 1080p30, 720p25, 720p30
IP Video Input: 1-ch
Audio Compression: G.711u
Two-way Audio: 1-ch RCA(2.0Vp-p, 1kÎ)
Video/Audio OutputHDMI/VGA Output: 1920 Ã 1080 / 60 Hz,1280 Ã 1024 / 60 Hz, 1280 Ã 720 / 60 Hz, 1024 Ã 768 / 60 Hz
Encoding resolution: When 1080p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF
When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF
Frame Rate: Main stream:
When 1080p Lite mode not enabled:
For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
When 1080p Lite mode enabled:
1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream: 2CIF@6fps; CIF/QVGA/QCIF@ 25fps (P)/30fps (N)
Video Bit Rate: 32 Kbps ~ 4 Mbps
Stream Type: Video/Video&Audio
Audio Output: 1-ch RCA(Linear, 1kÎ)
Audio Bit Rate: 64kbps
Dual Stream: Support
Synchronous Playback: 8-ch
